Nubion

Nubion-afterNubion-before

Taxi light – Simple drop-in replacement for old legacy light

FEATURES

9 High brightness LEDs for TAXI light coverage

Packed with 9 ultra high brightness CREE aviation white LEDs for TAXI mode.

Drop-In REPLACEMENT for old legacy lights

Waterproof / Shockproof / Dust-proof

All Aveo lights are waterproof, dust proof, and inert to most environmental conditions as they are all tested to categories of DO-160 exceeding the applicable requirements by far in external laboratories experienced in compliance demonstration of EASA ETSO appliances.

Environmentally Friendly

The Nubion™ uses far less power than competitive products illuminated by mercury-arc, high intensity discharge, or halogen lamps, which means they help to reduce air pollution from carbon emissions. Mercury and Lead-free, this RoHS compliant environmentally – friendly technology helps reduce power consumption and the amount of hazardous waste entering the environment. Finally, a “green” aircraft light!

Operating voltage:18-36V DC
Primary input voltage:28V DC
Over-voltage protection:80V (1s)
Input current at 28V:0.75A (+/- 5%)
Input current at 18V:1.2A (+/- 5%)
Reverse polarity protection:Yes
Over-Voltage shut down:38.5V DC
Under-Voltage protection:Yes
Operating temperature:from -55°C to +85°C / from -67°F to +185°F
Over-Temperature protection:Yes
Output power:18W
Weight:7.76oz (220g)

Installation Manual
